Storageconditionsforpackagedunit•Temperature:-25ºCto+55ºC
(–13ºFto131ºF)
•Relativehumidity:75%
Dimensions
•Width:237mm(9.33in)
•Height:170mm(6.69in)
•Depth:56mm(2.20in)
Weight
0.8kg(1.76lb)
Dataconnections
SeaTalk
hs
VideoinputsInputs1to3:
•Compositevideo(PAL:626lines,
NTSC525lines)
Input4:
•S-Videoorcompositevideo
Audioinput
Stereolinein(rated1VRMS),
associatedwithvideoinput4only
(S-Videoorcomposite)
Conformance•89/336/EECasamendedby
92/31/EEC
•EN60945:2002
10.3Commandcenterkeyboard
Technicalspecication
Nominalsupplyvoltage
12Vdc(fromSeaTalk
ng
bus)
Operatingvoltagerange
9to16Vdc
Typicalpowerconsumption1.5W
EnvironmentalInstallationenvironment
•Operatingtemperature:-15ºCto
+55ºC(5ºFto131ºF)
•Non-operatingtemperature:-25ºC
to+70ºC(–13ºFto158ºF)
•Relativehumiditylimit:95%
•Waterprotection:waterproofto
IPX6standard.
Storageconditionsforpackagedunit•Temperature:-25ºCto+55ºC
(–13ºFto131ºF)
•Relativehumidity:75%
Dimensions
•Width:297mm(11.69in)
•Height:98mm(3.86in)
•Depth:46mm(1.81in)
Weight
0.65kg(1.43lb)
150G-Seriesinstallationinstructions
