10-189

MULTIJUNCTION TIMERS

10.8 TOU (Output-Related 24-Bit Timer)

32180 Group User’s Manual (Rev.1.0)

Figure 10.8.15 Typical Operation in TOU Single-shot Output Mode (without Correction Function)

Count clock

H'FF FFFF

H'00 0000

Enabled

(by writing to the enable bit

or by external input)

F/F output

Disable

(due to underflow)

Interrupt request

due to underflow

Enable bit

Count down from the

reload 0 register set value

Note: • This diagram does not show detailed timing information.

Reload register

H'55 AA00

Counter

Data inverted by

enable

Data inverted by

underflow

H'(55 AA00-1)

Undefined

value
