Placing Originals
17
1
Placing Originals in the Auto Document Feeder
Place originals in ADF.
There are four types of special originals. Setting should be made in the following
situations:
❖ When placing originals consisting of more than 100 pages:
See “Batch Mode”.
❖ When placing originals one by one:
See “SADF Mode”.
❖ When placing originals of various sizes:
See “Mixed Sizes Mode”.
❖ When placing custom size originals:
See “Custom sizes”.
A Adjust the guide to the original size.
B Set the aligned originals face up into the ADF.
Do not stack originals beyond the limit mark.
The last page should be on the bottom.
Be sure not to block the sensor or load the original untidily. Doing so may
cause the machine to detect the size of the scanned image incorrectly or dis-
play a paper misfeed message. Also, be sure not to place originals or other ob-
jects on the top cover. Doing so may cause a malfunction.
A Sensors
To Next Page
