Optional Equipment
SM Appendix 1-11 D062/D063/D065/D066
Appendix:
General
Specifications
3-Hole (NA)
A3 SEF, B4 SEF, 11" x 17" SEF
A4 LEF, B5 LEF, 8.5" x11" LEF
4-Hole ( EUR/A)
A3 SEF, 11" x 17" SEF
A4 LEF, 8.5" x 11" LEF
Paper Weight
2-Hole (NA) 52 g/m
2
to 163 g/m
2
(14 to 43 lb)
3-Hole (NA) 52 g/m
2
to 163 g/m
2
(14 to 43 lb)
4-Hole (EUR/A) 52 g/m
2
to 128 g/m
2
(14 to 34 lb)
Punch Waste Hopper Capacity
2-Hole (NA) 10K
3-Hole (NA) 15K
4-Hole (EUR/A) 15K
Operation Modes All (Shift, Proof, Staple)
DIP SW Settings
The correct DIP SW settings of the Punch Unit 531 are provided in the table below for your
reference only. The DIP switches of these punch units do not need to be changed at
installation, or adjusted for operation.
DIP SW Settings
Punch Unit Unit No.
1 2 3 4
2/3-Hole (NA) B531-17 1 0 1 0
2/4-Hole (EUR/A) B531-27 1 0 0 1
0: OFF, 1: ON
