Service Call Conditions
D062/D063/D065/D066 3-82 SM Appendix
No. Location Position Code
122 Proof Tray Exit Sensor R1 to R4
123 Exit Sensor R1 to R4
124 Staple Entrance Sensor R5 to R7
125 Exit After Jogging R8 to R12
126 Corner Stapling S1
127 Saddle Stapling S2
128 Paper Folding R8 to R12
129 Shift Tray Motor R1 to R4
130 Jogger Fence Motor R8 to R12
131 Shift Roller Motor R1 to R4
132 Stapler Shift Motor R8 to R12
133 Stapler Motor R8 to R12
134 Folder Plate Motor R8 to R12
135 Feed Out Belt Motor R8 to R12
136 Paper Punch Motor R1 to R4
Finisher D460: Jam Codes
No. Location Position Code
151 Entrance Sensor R1 to R3
152 Proof Tray Exit Sensor R1 to R3
153 Shift Exit Sensor R1 to R3
154 Stapler Exit Sensor R4 to R7
⇒
Rev. 09/23/2009
