Service Program Mode Tables
SM Appendix 4-11 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
003 Charge Time
004 Worn-out Counter
005 Charged Power
1920
Capacitator Charge Setting: Japan only
1926
Capacitator Discharge: S-Size: Japan only
1927
Capacitator Discharge Setting: Japan only
1921
Idling Control: Japan only
-001
After Job Interval
C4c: [0 to 30 /0/1sec]
-002
After Job Target Temperature
C4c: [190 to 205/200/1deg]
1922
Heater Full Power Setting: Japan only
-001 0: OFF/1: ON
1923 HV Fusing Temp Cont
-001 0: OFF/1: ON
1924
10 Sec. Recovery Temperature: Japan only
-001
Temperature Sensor
C4c: [15 to 25/20/1]
1925
Idling Setting: Japan only
