Service Program Mode Tables
SM Appendix 4-13 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
[600 to 1500/650/10 V]
Use this if there is a copy quality problem when making OHP's.
006 Total Bias Grid Current: Photo Mode Total
Adjusts the voltage applied to the grid plate when Photo mode is selected.
[1400 to 2800/1500/10
A]
2101* Printing Erase Margin
These settings adjust the erase margin for the leading, trailing, left, and right
edges.
001 Leading Edge
[0 to 9/2.5/0.1 mm], Specification: 3±2 mm
002 Trailing Edge
[0 to 9/2/0.1 mm], Specification: 3±2 mm
003 Left Edge
004 Right Edge
[0 to 9/2/0.1 mm], Specification: 2±1.5 mm
2103
LD Power Adjustment DFU
Note: This is an SSP mode. To enter SSP mode, push [Reset], enter "107", then
hold down [Clear] for at least 3 sec. When you see "Copy SP" on the touch
panel, press and hold down [#] then touch "Copy SP".
001
LD0 Power
Adjustment
002
LD1 Power
Adjustment
003
LD2 Power
Adjustment
004
LD3 Power
Adjustment
These SP codes allow adjustment of the laser intensity for
each of the four channels.
[-64 to +64/0/1]
005 LD0 Adjustment
These SP codes allow adjustment of the start/end timing of
To Next Page
