OVERALL MACHINE INFORMATION
B513/B531 50 SM
Symbol Name Function
SOLENOIDS
SOL1
(Upper) Tray Junction
Gate
Drives the tray junction gate.
SOL2 Stapler Junction Gate
Drives the stapler junction gate.
SOL3 Pre-Stack Junction Gate
Drives the pre-stack junction gate.
SOL4 Pre-stack Paper Stopper
Drives the stopper pawl of the pre-stacking tray.
SOL5 Stapler Return
Positions the stapler correctly on its return from the
staple supply point.
SWITCHES
SW1 Shift Tray Upper Limit
Cuts the power to the shift tray lift motor when the
shift tray position is at its upper limit.
SW2 Front Door Safety
Cuts the dc power when the front door is opened.
SW3 Emergency Stop
Switches the current job off and on to allow time for
the operator to remove paper from the shift tray.
