2.General Operations For Servicing
59
b) In the Organization field, enter the name of your organization.
c) In the Country field, enter the name of your country (for example, use a two-letter country code).
d) Click Save.
e) Reboot the E-25C.
8. On the computer where you want to prevent untrusted connection messages, open Internet
Explorer and enter the IP address of the E-25C.
9. Click Continue to this website (not recommended).
10. At the top of the browser, click Certificate error then click View certificates.
11. In the Certificate dialog box, on the General tab, click the Install Certificate button.
12. In the Certificate Import Wizard dialog box, click Next and then do the following:
a) Select Place all certificates in the following store and click Browse.
b) In the Select Certificate Store dialog box, select Trusted Root Certification Authorities then click
OK.
13. Click Next.
14. When a pop-up indicates the completion of the certificate import wizard, click Finish.
15. If a security warning displays, click Yes.
16. When a pop-up indicates the import was successful, click OK.
17. To confirm, reopen WebTools using the IP address of the E-25C.
The URL now begins with https, the lock icon is green rather than red, and the lock icon is not
crossed out.
Accessing Configure from Command WorkStation
1. Make sure that Command WorkStation is installed in the client PC.
2. Launch Command WorkStation.
3. Connect to the E-25C and log in as Administrator.
4. Do one of the following to start Configure:
Click Server > Device Center > GENERAL and then click Configure at the lower right corner.
Click Server > Configure.
5. If the Fiery Setup dialog box displays, click Configure.
After changing some settings, make sure to click the "Save" button and then click Restart on
the upper bar, to effect the changes.
