Ricoh P C301W Field Service Manual

4.Replacement and Adjustment
109
• Printer model: Engine Maintenance > Fuser SC Detect
• MF model: Engine Service Setting > Fuser SC Detect
The default setting is "OFF". Select "ON" only if the customer wants to use this feature.
19. Adjust the registration for each direction (vertical and horizontal directions) and tray if necessary.
• Printer model: Engine Maintenance > Registration
• MF model: Engine Service Setting > Registration
20. Adjust the transfer roller bias for each paper type and for the front and back sides.
• Printer model: Engine Maintenance > 2nd Transfer
• MF model: Engine Service Setting > 2nd Transfer
21. Adjust the transfer roller bias and the temperature reduction of the fusing unit for each paper type
and for the front and back sides.
• Printer model: Engine Maintenance > Fuser Unit > Tar. Tp. speed1
• MF model: Engine Service Setting > Fuser Unit > Target Temp.speed1
22. Perform the color registration.
• Printer model: Engine Maintenance > Color Registration
• MF model: Engine Service Setting > Color Registration
MUSIC is performed.
23. If necessary, adjust the registration settings for the front and rear sides of each paper tray in the SP
mode.
24. For @Remote models, make sure that the manual call can be performed.
If the serial number is not entered correctly, @Remote service cannot be connected.
Controller Board (PCB2)
When you replace the controller board, the following counters stored on the controller board are
cleared:
• Scanner Counter
• Coverage
• Jam Counter
• Economy color print counter
The printer counter does not clear.
1. Remove the EGB. (Engine Board (EGB) (PCB1))

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
