Ricoh P C301W Field Service Manual

5.System Maintenance
127
5. System Maintenance
SP Mode Tables (Printer Model)
Overview
This machine has a service menu. The service menu has several adjustment items. This section
explains what you can do in each service menu.
Service menu
Description
Maintenance
Mode
Display Info
Displays the machine information. (Display Info)
Engine
Maintenance
Sets up for maintenance and service. (Engine
Maintenance)
Factory Default
Resets to the factory default. (Factory Default)
CTL Maintenance
Sets up for the controller. (CTL Maintenance)
System
Maintenance
Set up for the system maintenance. (System
Maintenance)
Test Pattern
Prints out the test pattern. (Test Pattern)
@Remote
Sets up for @Remote. (@Remote)
Entering the Service Menu
For further information, contact the supervisor in your branch office.
Selecting an Item
To select an item, press the [ ] or [ ] key.
Going into the Next Level/ Returning to the Previous Level
To go into the next level of an item, select an item then press the [OK] key.
To return to the previous level of an item, press the [Back] key.
Exiting the Maintenance Mode Menu
To exit the maintenance mode menu, press the [Clear/Stop] or [Back] key until the "Ready" display
appears.
Display Info
Menu
Description
Model Name
Displays the model name, depends on engine firmware
settings.
FW
CTL FW Version
Displays the firmware version.

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
