Ricoh P C301W Field Service Manual

6.Troubleshooting
237
Problem
Cause
Details
Solution
images
the development unit is
dropping onto paper
(paper path timing).
• Something has
jammed into the OPC
seal, allowing waste
toner to spill out.
operating in high
ambient
temperature and
humidity.
The problem
presents over time.
the machine.
If occurrence is
frequent, replace
the AIO.
White spots
appear in
images at
regular intervals
27 mm
intervals
Surface of the development
roller is contaminated with
foreign matter or small
divots.
The problem
presents over time.
Replace the AIO.
25 mm
intervals
There is a problem with the
image transfer roller.
The problem
presents over time.
Check the ITB or
replace the
image transfer
unit.
30 mm
intervals
There is a problem with the
charge roller.
The problem
presents over time.
Replace the AIO.
76 mm
intervals
OPC drum is scratched or
dirty.
Can occur at the
beginning of
machine use or
over time.
Replace the AIO.
78 mm
intervals
The surface of the fusing
sleeve belt or pressure
roller is scratched or dirty.
The problem
presents over time.
Check the fusing
unit or replace it.
At the pass of the first sheet,
white spots appear on both
sides of images at regular
intervals.
Paper dust remains in the
paper feed tray.
Paper in use has
too much paper
dust.
Clean the paper
dust in the paper
tray. (Cleaning
Points)
Uneven Color
Problem
Cause
Details
Solution
Part of the image
is missing from
center to trailing
edge of paper
Toner in the development
unit temporarily not
applied evenly.
Can occur when printing
light image areas
repeatedly.
Remove and reinstall
the AIO.
White spots
The AIO is not set
Can occur at the beginning
Remove and reinstall

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
