When using the four-line LCD panel model
1. Check that the router (access point) is working correctly.
2. Make sure the wireless LAN option is attached to the machine and the wireless (Wi-
Fi) connection is enabled.
3. Press the [User Tools] key.
4. Press the [ ] or [ ] key to select [Network Settings], and then press the [OK] key.
5. If you are requested to enter a password, enter the password using the number
keys, and then press the [OK] key.
A password for accessing the [Network Settings] menu can be specified in [Admin. Tools
Lock] under [Admin. Tools] menu.
6. Press the [ ] or [ ] key to select [Wireless (Wi-Fi)], and then press the [OK] key.
7. Press the [ ] or [ ] key to select [WPS], and then press the [OK] key.
8. Press the [ ] or [ ] key to select [PBC], and then press the [OK] key.
9. Press [Yes].
10. Press the WPS button on the router (access point) within two minutes.
For details about how to use the WPS button, refer to the manuals for the router (access point).
11. Check the result.
• Connection has succeeded:
"Connection to AP has Succeeded" is displayed.
Press [EXIT] to return to the screen displayed in Step 8, and then press the [User Tools]
key to return to the initial screen.
• Connection has failed:
"Connection to AP has Failed" is displayed.
Press the [EXIT] to return to the screen displayed in Step 8.
Check the configuration for the router (access point), then try the connection again.
12. Configuring the Wireless (Wi-Fi) settings is complete.
Using a PIN Code
A router (access point) is needed to set up a connection. To establish a connection using the PIN code,
use a computer that is connected to the router (access point).
Before doing the following procedure, install the printer driver according to the procedure on page 443
"Installing the Printer Driver".
Make sure the Ethernet cable is not connected to the machine.
Connecting the Machine to a Wireless Network
453
