Specifications A-5
Mechanical
Other
Resistance to
Vibration
Operational
Non-Operational
1.0 G Peak,
0.15 mm (0.006 in.) displacement
2.5 G,
0.38 mm (0.015 in.) displacement
Resistance to
Shock
Operational
Non-Operational
5.5 G
25 G
Construction Power Poles 5…85 A Heatsink thyristor modular design
108…480 A Heatsink hockey puck thyristor modular
design
Control Modules Thermoset and Thermoplastic Moldings
Metal Parts Plated Brass, Copper, or Painted Steel
Terminals Power
Terminals
5…85 A
Cable size — 2.5…85 mm
2
(#14…3/0 AWG)
Tightening torque — 14.7 N•m
(130 lb.-in.)
Wire strip length — 18…20 mm
(0.22…0.34 in.)
108…251 A Two M10 x 1.5 diameter holes per
power pole
317…480 A Two M12 x 1.5 diameter holes per
power pole
Power Terminal Markings NEMA, CENELEC EN50 012
Control Terminals M 3 screw clamp:
clamping yoke connection
EMC Emission
Levels
Conducted Radio Frequency
Emissions
Radiated Emissions
Class A
Class A
EMC Immunity
Levels
Electrostatic Discharge
Radio Frequency
Electromagnetic Field
Fast Transient
Surge Transient
8 kV Air Discharge
Per EN/IEC 60947-4-2
Per EN/IEC 60947-4-2
Per EN/IEC 60947-4-2
Overload
Characteristics
Current Range Line Delta
5 1…5 1.7…9
25 5…25 8.6…43
43 8.6…43 14.8…75
60 12…60 20.8…104
85 17…85 29.4…147
108 54…108 94…187
135 68…135 117…234
201 100…201 174…348
251 125…251 218…435
317 158…317 275…549
361 180…361 313…625
480 240…480 415…831
Trip Classes
Trip Current Rating
Number of Poles
10, 15, 20, and 30
117% of Motor FLC
3
Approvals Open Type Controllers CE Marked Per Low Voltage Directive
73/23/EEC, 93/68/EEC
UL Listed (File No. E96956)
CSA Certified (Class No. 3211-06)
