Rockwell Automation Allen-Bradley SMC-Flex 150 User Manual

3-14 Wiring
Figure 3.13 Typical Wiring Diagram for Isolation Applications (DPI also)
➀
Customer supplied.
➁ Refer to the controller nameplate to verify the rating of the control power input voltage.
➂ Aux #2 should be set for N.O..
11 12
13
14
15 16
17
18 19 20
21
23
24
25 26
27
28 29
30 31 32 33
22
34
SMC-Flex
Control Terminals
L1/1
L3/5
L2/3
T3/6
T2/4
T1/2
M
3-Phase
Input Power
Branch
Protection
SMC-Flex
Controller
Isolation
Contactor
(IC)
Alarm
Contact
PTC
Input
TACH
Input
Ground
Fault
Fault
Contact
Aux #2
Normal
Aux #1
Normal/Up-to-Speed/
Bypass
IC
Stop
Start
➀
➀
➀
➀
➀
➂
➁
➀
➀
➀
➀
