Rockwell Automation Allen-Bradley SMC-Flex 150 User Manual

Specifications A-7
➀ Use this row for 460V -58 and 575V -59.
➁ Use this row for 460V -59 and 575V -60 and -61.
Enclosed Type Delta-Connected Controllers
Controller
Rating (A)
IP65 (Type 4/12)
Disconnect Rating
(A)
B Height A Width C Depth
Combination Controllers with Fusible Disconnect
5 30 A/J 610 (24) 406 (16) 229 (9)
25 30 A/J 610 (24) 406 (16) 229 (9)
43 60 A/J 610 (24) 406 (16) 229 (9)
60 100 A/J 610 (24) 406 (16) 229 (9)
85 100 A/J 610 (24) 406 (16) 229 (9)
108 200 A/J 965 (38) 762 (30) 356 (14)
135 200 A/J 965 (38) 762 (30) 356 (14)
201 400 A/J 965 (38) 762 (30) 356 (14)
251 400 A/J 965 (38) 762 (30) 356 (14)
317 600 A/J 1524 (60) 965 (38) 356 (14)
361 600 A/J 1524 (60) 965 (38) 356 (14)
480
➀ 600 A/J 1524 (60) 965 (38) 356 (14)
480
➁ 800 A/J 2286 (90) 508 (20) 508 (20)
Combination Controllers with Circuit Breaker
5 15 A 610 (24) 406 (16) 229 (9)
25 30 A 610 (24) 406 (16) 229 (9)
43 80 A 610 (24) 406 (16) 229 (9)
60 100 A 610 (24) 406 (16) 229 (9)
85 125 A 610 (24) 406 (16) 229 (9)
108 175 A/175 A Plug 965 (38) 762 (30) 356 (14)
135 225 A/225 A Plug 965 (38) 762 (30) 356 (14)
201 300 A/300 A Plug 965 (38) 762 (30) 356 (14)
251 400 A/400 A Plug 965 (38) 762 (30) 356 (14)
317 600 A/600 A Plug 1295 (51) 914 (36) 356 (14)
361 600 A/600 A Plug 1295 (51) 914 (36) 356 (14)
480 800 A/800 A Plug 1295 (51) 914 (36) 356 (14)
Controller
Rating (A)
IP65 (Type 4/12)
B Height A Width C Depth
Non-Combination Controller
5 610 (24) 406 (16) 229 (9)
25 610 (24) 406 (16) 229 (9)
43 610 (24) 406 (16) 229 (9)
60 610 (24) 406 (16) 229 (9)
85 610 (24) 406 (16) 229 (9)
108 762 (30) 610 (24) 305 (12)
234 762 (30) 610 (24) 305 (12)
348 965 (38) 762 (30) 356 (14)
435 965 (38) 762 (30) 356 (14)
549 1524 (60) 914 (36) 356 (14)
625 1524 (60) 914 (36) 356 (14)
831 2286 (90) 635 (25) 508 (20)
