Appendix E
Renewal Part Cross Reference
➀ These are not orderable cat. nos. If a control module needs to be ordered, reference the control
module renewal part no. found in Appendix C.
Description
SMC
Rating
Line
Voltage
Input
Voltage
Orderable
Allen-Bradley
Renewal Part No.
Control Module
Internal Cat. No.
Label
➀
Control
Module
Standard All — 100…240V 41391-454-01-S1FX 150-FS1FX
All — 24V 41391-454-02-S2FX 150-FS2FX
Pump Control All — 100…240V 41391-454-01-B1FX 150-FB1FX
All — 24V 41391-454-02-B2FX 150-FB2FX
Brake Control 5…85 A — 100…240V 41391-454-01-D1AX 150-FD1AX
5…85 A — 24V 41391-454-02-D2AX 150-FD2AX
108…251 A — 100…240V 41391-454-01-D1BX 150-FD1BX
108…251 A — 24V 41391-454-02-D2BX 150-FD2BX
317…480 A — 100…240V 41391-454-01-D1CX 150-FD1CX
317…480 A — 24V 41391-454-02-D2CX 150-FD2CX
Control Type Control Voltage Line Voltage Amperes
Originally Ordered
AB Cat. No.
Series
Internal Control
Module Label
➀
Orderable Power
Poles
Standard 100…240V 200…480V AC 5 150-F5NBD A 150-FS1FX 150-FPP5B
25 150-F25NBD A 150-FS1FX 150-FPP25B
43 150-F43NBD A 150-FS1FX 150-FPP43B
60 150-F60NBD A 150-FS1FX 150-FPP60B
85 150-F85NBD A 150-FS1FX 150-FPP85B
200…600V AC 5 150-F5NCD A 150-FS1FX 150-FPP5C
25 150-F25NCD A 150-FS1FX 150-FPP25C
43 150-F43NCD A 150-FS1FX 150-FPP43C
60 150-F60NCD A 150-FS1FX 150-FPP60C
85 150-F85NCD A 150-FS1FX 150-FPP85C
24V AC/DC 200…480V AC 5 150-F5NBR A 150-FS2FX 150-FPP5B
25 150-F25NBR A 150-FS2FX 150-FPP25B
43 150-F43NBR A 150-FS2FX 150-FPP43B
60 150-F60NBR A 150-FS2FX 150-FPP60B
85 150-F85NBR A 150-FS2FX 150-FPP85B
200…600V AC 5 150-F5NCR A 150-FS2FX 150-FPP5C
25 150-F25NCR A 150-FS2FX 150-FPP25C
43 150-F43NCR A 150-FS2FX 150-FPP43C
60 150-F60NCR A 150-FS2FX 150-FPP60C
85 150-F85NCR A 150-FS2FX 150-FPP85C
