Wiring 3-13
Figure 3.12 Typical Wiring Diagram for Retrofit Applications
➀
Customer supplied.
➁ Overload protection should be disabled in the SMC-Flex controller.
➂ Refer to the controller nameplate to verify the rating of the control power input voltage.
➃ Aux #2 should be set for N.O.
11 12
13
14
15 16
17
18 19 20
21
23
24
25 26
27
28 29
30 31 32 33
22
34
Start
M
OL
Alarm
Contact
Fault
Contact
Aux #2
Normal
Aux #1
Normal/Up-to-Speed/
Bypass
SMC-Flex
Control Terminals
Stop
M
Branch
Protection
L2/3
L3/5
Input Power
3-Phase
SMC-Flex
Controller
T1/2L1/1
T2/4
T3/6
M
Existing Motor
Starter
PTC
Input
TACH
Input
Ground
Fault
➀
➀
➀➀
➀
➀
➀
➀
➀
➃
➂
➀➁
➀
