Rockwell Automation Allen-Bradley SMC-Flex 150 User Manual

Wiring 3-15
Figure 3.14 Typical Wiring Diagram for Shunt Trip Applications
➀
Customer supplied.
➁ Refer to the controller nameplate to verify the rating of the control power input voltage.
➂ Fault Contact should be set to N.O.
11 12
13
14
15 16
17
18 19 20
21
23
24
25 26
27
28 29
30 31 32 33
22
34
L1/1
L3/5
L2/3
T3/6
T2/4
T1/2
M
3-Phase
Input Power
Branch
Protection
SMC-Flex
Controller
Alarm
Contact
Fault
Contact
Aux #2
Normal
Aux #1
Normal/Up-to-Speed/
Bypass
SMC-Flex
Control Terminals
Start
Stop
ST
PTC
Input
TACH
Input
Ground
Fault
➀
➀
➀
➀
➀
➀
➀
➀
➂
➁
