Rockwell Automation MMI-HT-C2198-D032 User Manual

Design Guidelines
Transport System Design
100 MagneMotion
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Figure 3-29: MICS File Example (Continued)
<Motor> <!-- P1M4 -->
<Mac_addr>C0:6C:6D:E0:00:23</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.4</IP_addr> <!-- Motor IP address -->
<Track_location>P1M4</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M5 -->
<Mac_addr>C0:6C:6D:E0:00:24</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.5</IP_addr> <!-- Motor IP address -->
<Track_location>P1M5</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M6 -->
<Mac_addr>C0:6C:6D:E0:00:4E</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.6</IP_addr> <!-- Motor IP address -->
<Track_location>P1M6</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M7 -->
<Mac_addr>C0:6C:6D:E0:00:4F</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.7</IP_addr> <!-- Motor IP address -->
<Track_location>P1M7</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M8 -->
<Mac_addr>C0:6C:6D:E0:00:26</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.8</IP_addr> <!-- Motor IP address -->
<Track_location>P1M8</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M9 -->
<Mac_addr>C0:6C:6D:E0:00:3F</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.9</IP_addr> <!-- Motor IP address -->
<Track_location>P1M9</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M10 -->
<Mac_addr>C0:6C:6D:E0:00:36</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.10</IP_addr> <!-- Motor IP address -->
<Track_location>
P1M10</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<Motor> <!-- P1M11 -->
<Mac_addr>C0:6C:6D:E0:00:AF</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.1.11</IP_addr> <!-- Motor IP address -->
<Track_location>P1M11</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
<!-- PATH 2 -->
<Motor> <!-- P2M1 -->
<Mac_addr>C0:6C:6D:E0:00:AB</Mac_addr> <!-- Motor MAC address -->
<IP_addr>10.14.2.1</IP_addr> <!-- Motor IP address -->
<Track_location>P2M1</Track_location> <!-- Track NC Path, Motor # -->
</Motor>
