4.
Alignment
and
T
roubleshooting
4.1.3.8.
Paper
jam
at
the
exit
of
the
nisher
1.
Remove
the
jammed
paper
by
pulling
in
the
direction
shown.
T
o
avoid
tearing
the
paper
,
pull
it
out
gently
and
slowly
.
0
0
2.
Close
the
nisher’
s
rear
cover
.
0
4.1.3.9.
Paper
jam
in
front
of
the
multi-bin
mailbox
1.
Open
the
mailbox’
s
rear
cover
.
0
2.
Open
the
machine’
s
rear
cover
.
0
4-13
Copyright©
1995-2016
SAMSUNG.
All
rights
reserved.
113
115
