2.ProductSpecicationsandDescription
2.2.11.4.Finishermainboard
Thefollowingdiagramdisplaystheconnectioninformationofthenishermainboard.
ConnectorNumberName
P/J1PSU(+24V ,+5V),ENGINEINTERFACE
P/J2StaplerDoor/SafetySwitch
P/J5FeedingMotorsandExtensionTrayMotor
P/J6TamperMotors
P/J7Stacker,ExtensionTray,Diverter,EntranceSensors
P/J8Exit,JamCover,TamperSensors
P/J9StaplerMotorsandSensors
P/J14StackerMotor
Copyright©1995-2016SAMSUNG.Allrightsreserved.2-58
