2.ProductSpecicationsandDescription
2.2.12.Mailbox
2.2.12.1.Mailboxlayout
Thefollowingdiagramdisplaysthecrosssectionalview.
1
2
3
4
5
6
7
8
9
10
11 12
13
14
15
16
17
18
19
20
No.NameNo.Name
1EntranceSensor11FullSensor:Bin#4
2ExitSensor:Bin#112ExitRoller:Bin#4
3LowerGateSensor13FeedRoller:Bin#4
4FullSensor:Bin#114ExitRoller:Bin#3
5ExitSensor:Bin#215FeedRoller:Bin#3
6FullSensor:Bin#216ExitRoller:Bin#2
7ExitSensor:Bin#317FeedRoller:Bin#2
8UpperGateSensorLevelSensor18ExitRoller:Bin#1
9FullSensor:Bin#319FeedRoller:Bin#1
10ExitSensor:Bin#420AS-COVERJAMFRAMEASSY
