2.ProductSpecicationsandDescription
2.2.10.7.JointPBA
TheJointPBAprovidestheinterfaceforclutch,sensor,motors.
1
2
3
4
5
6
7
•Information
-SEC-CODE:JC92-02374A
-PBAName:JointPBA
•Connection
1Cover-OpenIF
2TonerDCMotorIF
3MPSensorIF
4MPClutchIF
5PaperSenorIF,Pickup&DulpexClutchIF
6RegiClutchIF
7MainIFFFCCable
2.2.10.8.DeveCrumJointPBA
TheDeveCrumJointPBAistheinterfacePBAbetweentheImagingUnitandthesystem.
•Information
•SEC-CODE:JC92-02163A
•PBAName:DEVECRUMJOINT
