2.ProductSpecicationsandDescription
2.2.8.LaserScanningUnit
2.2.8.1.LaserScanningUnitOverview
TheLaserScanningUnit(LSU)consistsofonepolygonmotorandoneLD(LaserDiode),andformsalatentimageonthe
surfaceofOPCdrum.Forthisprocess,thereisaC-DOElens,F-ThetaLens,reectivemirror(thatchangeslaserbeam
path),thecoverglassforprotectingtheLSUfromcontamination.Also,LDPBAislocatedtothefrontforinterface.
ThePDsensorlocatedinLDPBAdetectsthescanningstartlineandgeneratesthehorizontalsyncsignal(Hsync).
ThepicturebelowshowsthemaincomponentsforLSU.
NOTE
TheLSUistheopticalprecisiondevice.Pleasehandleitcarefullyanddonotremovethecover.
3
4
2
5
S c a n {
{
÷
÷
Þ
Þ
V
V
{
{
÷
÷
P D S e n s o r
1
Re flec tio n Mirror
1LDPBA
2P/MirrorMotor
3F-Lens
4ReectMirror
5CoverGlass
•Information
PartCode:JC97-03877A[LSU]
Copyright©1995-2016SAMSUNG.Allrightsreserved.2-30
