2.ProductSpecicationsandDescription
2.2.11.3.Electricalpartslocation
Thefollowingdiagramdisplaystheelectricalpartssuchassensorandmotor.
M
M
2
2
M
M
1
1
M
M
4
4
M
M
5
5
M
M
3
3
M
M
6
6
M
M
7
7
S
S
2
2
S
S
7
7
S
S
9
9
S
S
8
8
SS 44
S
S
3
3
S
S
6
6
S
S
5
5
S
S
1
1
P
P
1
1
S
S
1
1
0
0
SS 11 11
S1JC81-07420AAS-SENSOR:KIT5011CEntranceSensor
S2JC81-07420AAS-SENSOR:KIT5011CDiverterSensor
S3JC81-07420AAS-SENSOR:KIT5011CJamGuideSensor
S4JC81-03480AAS-SENSOR:KIT5011CExitSensor
S5JC81-07420AAS-SENSOR:KIT5011CTamperHomeSensor(Front)
S6JC81-07420AAS-SENSOR:KIT5011CTamperHomeSensor(Rear)
S7JC81-07420AAS-SENSOR:KIT5011CExtensionTrayHomeSensor
S8JC81-07420AAS-SENSOR:KIT5011CLevelSensor
S9JC81-07420AAS-SENSOR:KIT5011CStackerFullSensor
S10MSW33143MICROSWITCH:VP333A-4DStapleSafetySwitch
S11MSW33113MICROSWITCH:VP333A-1DCoverOpenSwitch
M1JC81-03478AASSY:PMMOTOR:S2M20TFeedEntranceMotor
M2JC81-03479AASSY:HBMOTOR:S2M19TFeedExitMotor
M3HF103139ASSY:PMMOTOR:M08Z18FrontTamperMotor
M4HF103139ASSY:PMMOTOR:M08Z18RearTamperMotor
M5JC81-03478AASSY:PMMOTOR:S2M20TExtensionTrayMotor
M6JC81-03475ABSTAPLER:EH-C590SSStaplerMotor
M7JC81-08264AAS-DCMOTOR:2738:S2M12T:PCBStackerMovingMotor
P1HF108200PCBASSY :MAIN:HF-FINFinisherPCB
2-57Copyright©1995-2016SAMSUNG.Allrightsreserved.
