SATO CL6NX User Manual

213
When to Replace Media and Ribbon
Checking the Remaining Amount of Media and Ribbon
You can check the remaining amount of media and ribbon according to the following procedure.
• Checking through the window on the right side of the printer
You can visually check the remaining amount of media and ribbon in the printer through the window
on the right side of the printer (1).
• Checking through the notifications of the printer
The printer has Near End and End detection functions for the media and ribbon.
With icons and error messages on the display of the printer, you can check if you need to replace
the media or ribbon soon, or if the remaining amount of media and ribbon is scarce.
*Label Near End is supported on printers from serial number 6B~ and above.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
