Supported Interfaces
752
Interface
Supported Interfaces
For data communication with the host, the printer supports the following interfaces.
Standard
• USB Interface (Type B)
• LAN Interface (Ethernet)
• Bluetooth Interface
• NFC Interface
*This feature is supported on printers from serial number 6B~ and above.
• USB Interface (Type A) x 2
• RS-232C Interface (DB 9 pins, female)
• IEEE1284 Interface (Amphenol 36 pins)
• External Signal (EXT) Interface (Amphenol 14 pins)
Option
• Wireless LAN Interface
RFID (CL4NX only)
UHF (920 MHz)
ISO/IEC 18000-6 Type C Gen2
UHF (13.56 MHz)
ISO/IEC 15693 (ICODE SLI/SLIX/SLIX-S, Tag-it HF-I, my-d)
ISO/IEC 14443 Type A (NTAG203, NTAG210, NTAG213/215/216, MIFARE UltraLight, MIFARE
UltraLight C, my-d move NFC)
ISO/IEC 18092 (FeliCa Lite-S)
• Do not connect or disconnect the interface cables (or use a switch box) with power
supplied to either the printer or host. This may cause damage to the interface circuitry
in the printer or host and is not covered by warranty.
• Wireless LAN is an optional interface.
• You cannot use the wireless LAN interface and LAN interface at a time.
• You can set the interface settings of the printer through [Interface] in the [Settings]
menu.
