SATO CL6NX User Manual

227
Dispenser
Peel the liner from the printed label as the label is fed to the printer’s front. Once the printed label
has been removed from the printer for application, the next label will retract and position itself for
printing. You can specify this option only if you have installed the dispenser unit.
Linerless (CL4NX only)
Cut each label while printing the specified number of labels. You can specify this option only if you
have installed the linerless cutter kit.
• If no option is installed, [Continuous] and [Tear-Off] are available.
• If the optional cutter unit is installed, [Continuous], [Tear-Off], [Cutter], and [Cut & Print]
are available.
• If the optional dispenser unit is installed, [Continuous], [Tear-Off], and [Dispenser] are
available.
• If the optional linerless cutter kit is installed to CL4NX, only [Linerless] is available.
• You cannot set the [Print Mode] if [Auto-mode] is [Enabled].
[Backfeed]
[Backfeed] is applicable only when the print mode is set to tear-off mode, cutter mode, cut & print
mode, dispenser mode or linerless mode (CL4NX only).
The options are as follows:
None
Do not backfeed.
After
After cut, backfeed the front part of the next media to the print head position. For dispenser mode,
backfeed the front part of the next label after dispensing the label.
Before
Before printing, backfeed the front part of the next media to the print head position.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
