SATO CL6NX User Manual

Dashboard
508
Dashboard
[Dashboard] is the default page of WebConfig. Each section shows specific information or status of the
printer.
• You can view [Dashboard] page without logging in.
(1) [Printer Status]
Shows the current state (Online, Offline, error) and current status icons.
(2) [Printing]
Shows the print speed, darkness, sensor, print mode and backfeed setting.
(3) [Device]
Shows the model, current resolution and options that are installed.
(4) [Network]
Shows the current IP address and MAC address of the active interface.
(5) [System]
Shows the current firmware version, uptime, SNMP contact, name and location.
(6) [Wi-Fi]
Shows the current Wi-Fi setting.
• This information is shown only if Wi-Fi is available and active.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
