SATO CL6NX User Manual

491
◦ Appears only if the LAN interface is selected.
Wi-Fi MAC
Shows the MAC address of the wireless LAN.
◦ Appears only if the optional wireless LAN is installed and the Wi-Fi interface is selected.
Wi-Fi Region
Shows the region information of the wireless LAN.
◦ Appears only if the optional wireless LAN is installed and the Wi-Fi interface is selected.
Wi-Fi Status
Shows the status of the wireless LAN.
◦ Appears only if the optional wireless LAN is installed and the Wi-Fi interface is selected.
Wi-Fi Direct
Shows the connection information of Wi-Fi Direct.
◦ Appears only if connected using Wi-Fi Direct.
Wi-Fi Versions
Shows the version of the wireless LAN.
◦ Appears only if the optional wireless LAN is installed and the Wi-Fi interface is selected.
[Help]
Shows the guidance video.
You can view the video for loading the media and ribbon, the cleaning method and replacement
method of consumables.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
