SATO CL6NX User Manual

219
[Printing] Menu
The following settings are available in the [Printing] menu:
Label Length
Set the length of the media.
Label Width
Set the width of the media.
Auto Measure
Automatically measure the length of the media.
Ribbon
Set whether to print using a ribbon or direct thermal media.
Ribbon Near End
Enable or disable the warning when the ribbon is about to run out.
◦ Appears only if you have selected [Use Ribbon] in the [Ribbon] menu.
Speed
Set the print speed.
Sensor Type
Set the media sensor type.
Auto-mode
Automatically set the print mode.
Print Mode
Manually set the print mode.
Backfeed
Set the backfeed operation.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
