Hardware Features
Communication Connections
38
| 100
Siemens Industry, Inc.
Technical Reference Manual
145-172
Building Technologies
Restricted
2018-09-25
NOTE:
A P1 FLN license must be installed in order to use Wireless FLN.
NOTE:
The PXC Compact on P1 is not supported on the Wireless FLN.
The following additional hardware is required to implement the Wireless P1 FLN with
the PXC Compact Series:
● Field Level Network Transceiver (FLNX)
● Field Panel Transceiver (FPX)
See the section Minimum Firmware Revision Required [➙ 10] for information on the
firmware revision required to implement Wireless P1 FLN.
PXC Compact on P1
The PXC-16 and the PXC-24 may be configured to reside on the P1 Field Level
Network (FLN). When configured for the FLN, the PXC Compact functions as a
programmable FLN device, which accepts custom applications.
PXC Compact on P1
The PXC-16 and the PXC-24 may be configured to reside on the P1 Field Level
Network (FLN). When configured for the FLN, the PXC Compact functions as a
programmable FLN device, which accepts custom applications.
See the section
Minimum Firmware Revision Required for information on the firmware
revision required to implement operation on the P1 FLN.
Virtual AEM
Without additional hardware, the Virtual AEM connects an RS-485 APOGEE
Automation Level Network (ALN) or individual RS-485 field panels to a P2 Ethernet
network.
● An additional license is required.
Virtual AEM
● The Virtual AEM is fully configurable from the HMI. Configuration is the same as for
hardware AEM.
● Even though hardware is not connected to the HMI port, the settings for the
HMI/Modem are used to select Alarm Printing/Report Printing, BLN Descriptor, and
BLN NAME.
– The Alarm Printing and Report Printing settings have no effect on AEM
operations (Virtual or hardware).
– Baud rate settings have no effect on the data transmission.
