6-1
DCR-TRV9/TRV9E
SECTION 6
REPAIR PARTS LIST
6-1. EXPLODED VIEWS
NOTE:
• -XX, -X mean standardized parts, so they may
have some differences from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• The mechanical parts with no reference number
in the exploded views are not supplied.
• Hardware (#mark) list is given in the last of
this parts list.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
6-1-1. FRONT PANEL SECTION
a
a
1
2
3
16
4
4
5
6
7
8
9
10
11
11
11
11
11
11
11
11
13
13
13
12
12
12
not supplied
not supplied
not supplied
not supplied
MIC901
15
14
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1 X-3948-452-1 CAP ASSY, LENS
2 X-3948-459-1 PANEL ASSY, FRONT (TRV9E:AEP,UK)
2 X-3948-637-1 PANEL ASSY, FRONT
(TRV9/TRV9E:EXCEPT AEP,UK)
3 X-3948-601-1 HOLDER ASSY, MICROPHONE
4 A-7073-518-A MA-322 BOARD, COMPLETE (TRV9)
4 A-7073-598-A MA-322 BOARD, COMPLETE (TRV9E:AEP,UK)
4 A-7073-619-A MA-322 BOARD, COMPLETE
(TRV9E:EXCEPT AEP,UK)
5 1-669-511-11 FP-654 FLEXIBLE BOARD
6 1-475-707-11 SWITCH BLOCK, CONTROL (MF4580)
7 1-694-411-11 TERMINAL BOARD, BATTERY
8 X-3948-460-1 HOLDER ASSY, BATTERY
9 3-988-463-01 CABINET (UPPER)
10 3-713-791-51 SCREW (M1.7X3.5), TAPPING, P2
11 3-968-729-01 SCREW (M2), LOCK ACE, P2
12 3-968-729-81 SCREW (M2), LOCK ACE, P2
13 3-948-339-61 TAPPING
14 1-475-141-21 REMOTE COMMANDER RMT-808
(TRV9/TRV9E:EXCEPT AEP,UK)
14 1-475-141-31 REMOTE COMMANDER RMT-809
(TRV9E:AEP,UK)
15 3-742-854-21 LID, BATTERY CASE
* 16 3-050-355-01 CUSHION (A), MN
MIC901 1-542-350-11 MICROPHONE UNIT
