2-3
2-5. EVF CABINET (UPPER) ASSEMBLY, EVF CABINET (LOWER) ASSEMBLIES
2-6. LCD ASSEMBLY
1 Screw (M2 × 4)
3 Screw (M1.7 × 6)
1 Screw (M1.7 × 6)
4 EVF cabinet (upper) assembly
9 VF lens assembly (458)
5 EVF cabinet
(lower) assembly
8 Remove the claw.
2 VF frame
!¢ Fluorescent display tube (LCD902)
!∞ LCD cushion-1
!£ LCD cushion (458)
!™ BL diffusion plate (458)
!¡ LCD cushion (458) Glaring faces of both must fac
e
with !™ .
!º LB-55 board
7 LCD902
(from CN5202 of LB-55 board)
6 FP-655
flexible board
a
a
b
b
!¢ P cabinet (M)
assembly
Claws
Claws
!£ LCD display module
(LCD901)
!™ Tube, fluorescent cold
cathode (3.5) (ND901)
6 Screw (M2 × 4)
5 Screw
(M2
× 4)
9 Screw (M1.7 × 2.5)
3 Screw (B2 × 5)
7 Claws
P cabinet (C) assembly
8 LCD901
(From CN5801 of PD-98 board)
8 ND901
(From CN5701 of PD-98 board)
8 Function switch block
(BV4680)
(From CN5805 of PD-98 board)
!º PD-98 board
8 FP-649 flexible board
(From CN5802 of PD-98 board)
!¡ Panel frame
assembly
4 Remove the LCD unit
from R cabinet.
While holding it toward inside,
Open
2 Open the retainer of panel flexible board
1 FP-649
flexible board
PD-98
7 Claws
Claws
Claws
