2-2
2-3. CABINET (R) ASSEMBLY
2-4. EVF ASSEMBLY
2 Screw (M1.7 × 3.5)
2 Screw (M1.7 × 3.5)
2 Screw (M1.7 × 3.5)
3 SP retainer assembly
11 Harness
From CN7801 of
KY-39 board
1 FP-649 flexible board
(From CN7802 of KY-39 board)
4 Speaker (SP901)
Cabinet (R) assembly
1 FP-657 flexible board
(From CN7804 of KY-39 board)
1 FP-656 flexible board
(From CN7806 of KY-39 board)
1 Function switch block
(CF4580)
(From CN7803 of KY-39 board)
* Notes when attaching the cabinet (R) assembly
KY-39 board
Align S7823 position with that of
START/STOP switch.
Board
KY-39
The numbers in square `
show the sequence in the
case when the speaker
(SP901) onlyis removed.
22 Screw
(M1.7 × 3.5)
2 Screw
(M2 × 3)
5 Insert pincers and disengage
the claw in the direction of the arrow
To assemble it, engage
the EVF slide base
with the claw.
Claw
4 Slide the EVF.
9 Move the VF-121
board in the direction
of the arrow a .
!¡ Move the VF flexible clamper
in the direction of the arrow c .
0 Push the claw in the direction
of the arrow b , and
8 Push the both claws
at the same time with
pincers, and remove it.
7 FP-655
flexible board
6 VF ornamental panel
a
b
c
33
Remove it
by sliding.
11 FP-656 flexible board
(From CN7806 of KY-39
board)
8 FP-657 flexible board
(From CN7804
of KY-39 board)
6 While
depressing
the claw
5 Hinged flexible sheet
7 Remove by
depressing it
down once.
4
!™
!£ Disengage the claw.
!¢ FP656 flexible board
VF board holder
!∞ VF121 board
!§ Disengage the catch.
!¶ VF flexible clamper
The numbers in square ` show the
sequence in the case when the
FP-657 flexible board only is removed.
