5-14
8. Color Reproduction Adjustment
Adjust the color Separation matrix coefficient so that proper color
reproduction is produced.
Subject Color bar chart standard picture frame
Measurement Point Video output terminal
Measuring Instrument Vectorscope
Adjustment Page F
Adjustment Address 2E, 30, 44, 45
Specified Value All color luminance points should
settle within each color reproduction
frame.
Switch setting:
1) NIGHT SHOT switch ......................................................OFF
Adjusting method:
1) Select page: 6, address: 00, and set data: 01.
2) Select page: 6, address: 01, set data: 3D, and press the PAUSE
button of the adjustment remote commander.
3) Select page: F, address: 16, set data: 37, and press the PAUSE
button of the adjustment remote commander.
4) Adjust the GAIN and PHASE of the vectorscope, and adjust
the burst luminance point to the burst position of the color
reproduction frame.
5) Change the data of page: F, address: 2E, 30, 44 and 45, and
settle each color luminance point in each color reproduction
frame.
Note: Be sure to press the PAUSE button of the adjustment remote
commander before changing the addresses. If not, the new data
will not be written to the memory.
6) Press the PAUSE button of the adjustment remote commander.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, and set data: 00, and press the
PAUSE button of the adjustment remote commander.
2) Select page: 6, address: 00, and set data: 00.
For NTSC model
For PAL mode
Fig. 5-1-9
Burst position
Burst position
