5-1
DCR-TRV9/TRV9E
SECTION 5
ADJUSTMENTS
5-1. CAMERA SECTION ADJUSTMENT
NTSC model : DCR-TRV9
PAL model : DCR-TRV9E
1-1. PREPARATIONS BEFORE ADJUSTMENT (CAMERA SECTION)
1-1-1. List of Service Tools
• Oscilloscope • Regulated power supply • Vectorscope
• Color monitor • Digital voltmeter
J-1 J-2
J-6
J-3
J-7 J-8
J-4 J-5
Fig. 5-1-1.
J-9 J-10
J-11 J-12
When performing adjustments, refer to the layout diagrams
for adjustment related parts beginning from page 5-28.
Note: If the microprocessor IC in the adjustment remote commander is not the new microprocessor (UPD7503G-C56-12), the pages cannot be switched.
In this case, replace with the new microprocessor (8-759-148-35).
Ref. No.
J-1
J-2
J-3
J-4
J-5
J-6
J-7
J-8
J-9
J-10
J-11
J-12
Name
Filter for color temperature correction (C14)
ND filter 1.0
ND filter 0.3
Pattern box PTB-450
Color chart for pattern box
Adjustment remote commander (RM-95 upgraded). Note
Siemens star chart
Clear chart for pattern box
Multi CPC jig
CPC-8 jig
Extension cable (100P, 0.4mm)
Extension cable (70P, 0.5 mm)
IR receiver jig
Parts Code
J-6080-058-A
J-6080-808-A
J-6080-818-A
J-6082-200-A
J-6020-250-A
J-6082-053-B
J-6080-875-A
J-6080-621-A
J-6082-311-A
J-6082-388-A
J-6082-413-A
J-6082-414-A
J-6082-383-A
Usage
Auto white balance adjustment/check
White balance adjustment/check
White balance check
White balance check
For checking the flange back
For adjusting the LCD
For adjusting the video section
For adjusting the viewfinder
For extension between the AU-202 board (CN7501) and
the VC-206 board (CN9902)
For extension between the DD-106 board (CN3902) and
the VC-206 board (CN9911)
For adjusting the IR transmitter
To Next Page
