2-4
2-7. AU-202 BOARD, DD-106 BOARD, BATTERY HOLDER ASSEMBLY
2-8. ZOOM LENS
1 Screw (M2 × 3)
4 Screw (M2 × 3)
5 DD-106 board
1 Screw
(M2
× 4)
1 Screw
(M2
× 4)
2 Battery holder assembly
3 Connector
from CN3901
of DD-106 board
Board
AU-202
The numbers in square ` show
the sequence in the case when the
AU-202 board only is removed.
2
6 Screw (M2 × 3)
2 Screw (M2 × 3)
6 Screw (M1.7 × 6)
5 Cushion (L)
7 CD-185 board
7 CD-185 board
1 CD-185 board CN451
(from CN201 of VC-206 board)
4 Flexible board
from CN452 of
CD-185 board
3 Zoom lens
(VCL-5115VA)
2-9. VC-206 BOARD
1 FP-648
flexible board
(CN9901)
1 FP-654 flexible board
(CN9905)
3 VC-206 board
1 FP-653
flexible board
(CN9908)
2 Screw (M2 × 3)
1 FP-647
flexible board (CN9910)
1 FP-650
flexible board (CN9909)
1 From mechanism deck (CN2701, 3100, 3103, 3106)
1 FP-676
flexible board
(CN9907)
2 Screw (M2 × 3)
VC-206 Board
