5-5
1-2. INITIALIZATION OF F, E PAGE DATA
1. Initializing the F, E Page Data
Note: If the F, E page data has been initialized, “Modification of F, E PAGE
Data” and the camera system adjustments need to be performed
again.
Adjusting page F
Adjusting Address 00 to FF
Adjusting page E
Adjusting Address 00 to 33
Initializing Method:
1) Select page: 6, address: 00, and set data: 01.
2) Select page: 6, address: 01, and set data: 2D (NTSC) or data:
2F (PAL).
3) Select page: 6, address: 03, set data: 01, and press the PAUSE
button of the adjustment remote commander.
4) Select page: 6, address: 02, and check that the data is “01”.
5) Select page: 6, address: 00, and set data: 00.
6) Perform “Modification of F, E Page Data”.
2. Modification of F, E PAGE Data
If the F, E PAGE data has been initialized, change the data of the
“Fixed data-2” address shown in the following tables by manual
input.
Modifying Method:
1) Before changing the data, select page: 6, address: 00, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the camcorder
may not operate.
3) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
5) After changing the data, select page: 6, address: 00, and set
data: 00.
3. F Page Table
Note: Fixed data-1 : Initialized data. ( Refer to “1. Initializing the F, E
Page Data”.)
Fixed data-2 : Modified data. (Refer to “2. Modification of F, E
PAGE Data”).
Address
00 to 0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
Initial value
NTSC
80
80
40
90
3E
43
59
FB
1D
87
2A
79
13
00
00
64
22
27
88
6C
00
00
46
00
19
00
21
02
34
7A
PAL
80
80
40
90
3E
43
59
FB
1D
87
2A
79
13
00
00
64
22
27
88
6C
00
00
46
00
19
00
21
02
34
7A
Remark
Fixed data-1
(Initialized data)
36MHz origin osc. adj.
Fixed data-1
HALL adj.
AWB standard data input adj.
Flange back adj.
Max gain adj.
Fixed data-1
Color reproduction adj.
Fixed data-1
Color reproduction adj.
Fixed data-1
(Initialized data)
Auto white balance adj.
Flange back adj.
AWB standard data input adj.
To Next Page
