Sony DFS-900M User Manual

141
Customizing DME Effects
Chapter 5 Adjusting Wipes and Keys
a) Shown only in GUI menu screens
b) xxx: “M/E DME” appears if you are setting up a transition, and “Keyer”
appears if you are setting up a key.
c) xxx: “Keyer” appears only if you are setting up a key.
To display the WARP sub menus
When using the BKDF-901: Press the SHIFT button in
the DME/SETUP block, turning it off, and then press
the WARP button.
When using the BKDF-902: Press the WARP button in
the DME/SETUP block.
The most recently used sub menu appears in the display
panel.
To switch between sub menus, press the WARP button
repeatedly until the sub menu that you want appears.
Ripple sub menu parameters
Adjust the following parameters to adjust the ripple effect.
Ripple effect example
The Ripple sub menu has four pages. To switch between
pages, press the h and H buttons in the numeric
keypad.
(xxx: “M/E DME” appears if you are setting up a
transition, and “Keyer” appears if you are setting up a key.)
xxx Ripple 1 (1)
xxx Ripple 2 (2)
xxx Ripple 3 (3)
Page Peel
a)
Adjust the parameters of
the Page Peel effect.
224 to 231
Splits
a)
Adjust the parameters of
the Splits effect (which
divides the video into
separate segments).
232 to 241
Mirror
a)
Adjust the parameters of
the Mirror effect.
242 to 249
xxx Defocus
c)
(Defocus)
Adjust the parameters of
the Defocus effect
(which blurs the overall
video image).
252
Sub menu Operation Operation target
pattern
numbers
Operation Knob Parameter Settings
Select the ripple
type.
F1 Typ (Shape
Type)
Hor: Horizontal
waves
Ver: Vertical waves
Rot: Rotating
waves
Cir: Circular ripple
Poly: Polygonal
ripple
Star: Star shaped
ripple
Select the ripple
frequency.
F2 Frq (Freq) –100.0 to 100.0
Select the ripple
amplitude.
F3 Amp –2.000 to 2.000
Select the ripple
phase.
F4 Phs (Phase) –8.000 to 8.000
Operation Knob Parameter Settings
Select the wave
type.
F1 Wav (Wave
Type)
Sine: Sine wave
Square: Square
wave
Triangle: Triangle
wave
Saw: Saw wave
Random: Random
wave
Adjust the
rotation of the
waves.
F2 Rot
(Rotation)
–8.000 to 8.000
Select the
number of apex
points of the star
shape (when
Star is
selected).
F3 Pnt (Points) 2 to 16
Select the
sharpness of
the star shape
(when Star is
selected).
F4 Shp
(Sharpness)
–100.0 to 100.0
Operation Knob Parameter Settings
Specify the
number of sides
(when Poly is
selected).
F1 Sid (Sides) 2 to 32
Specify the X
coordinate of
the center point
of the waves.
F2 PX (Position
X)
–8.000 to 8.000
Specify the Y
coordinate of
the center point
of the waves.
F3 PY (Position
Y)
–8.000 to 8.000
