Customizing DME Effects
Chapter 5 Adjusting Wipes and Keys
xxx Modifier (Modifier)
Swirl sub menu parameters
Adjust the following parameters to adjust the swirl effect.
Swirl effect example
Mosaic sub menu parameters
Adjust the following parameters to adjust the Mosaic
effect.
Mosaic effect example
The Mosaic sub menu has two pages. To switch between
pages, press the h and H buttons in the numeric
keypad.
(xxx: “M/E DME” appears if you are setting up a
transition, and “Keyer” appears if you are setting up a key.)
xxx Mosaic 1 (1)
xxx Mosaic 2 (2)
Slats sub menu parameters
Adjust the following parameters to adjust the Slats effect.
Slats effect example
Operation Knob Parameter Settings
Select whether
to modify the
ripple.
F1 Mod
(Modifier)
On: Modify
Off: Do not modify
Multi-wave F2 Zom (Zoom) –8.000 to 8.000
Specify the
aspect ratio of
the multi-wave.
F3 Asp
(Aspect)
–8.000 to 8.000
Operation Knob Parameter Settings
Specify the X
coordinate of
the center of the
swirl.
F2 PX (Position
X)
–8.000 to 8.000
Specify the Y
coordinate of
the center of the
swirl.
F3 PY (Position
Y)
–8.000 to 8.000
Specify the
amount of
swirling.
F4 Amt
(Amount)
–1.000 to 1.000
Operation Knob Parameter Settings
Select the type
of Mosaic effect.
F1 Typ (Type) Nor: Normal
mosaic
Rot: Rotated
mosaic
Specify the
aspect ratio of
one tile.
F2 Asp
(Aspect)
–8.000 to 8.000
Specify the size
of one tile.
F4 Siz (Size) 0.00 to 32.00
Operation Knob Parameter Settings
Specify the X
coordinate of
the center of the
mosaic.
F2 PX (Position
X)
–8.000 to 8.000
Specify the Y
coordinate of
the center of the
mosaic.
F3 PY (Position
Y)
–8.000 to 8.000
Adjust the
rotation of the
mosaic.
F4 ROT
(Rotation)
–8.000 to 8.000
Operation Knob Parameter Settings
Select the way
in which the
slats are
arranged.
F1 Typ (Shape
Type)
Hor: Horizontal
Ver: Vertical
HV: Horizontal and
vertical
Rot: Rotated
HV-R: Rotated
horizontally and
vertically
Specify the
rotation angle of
the slats.
F2 Rot
(Rotation)
–8.000 to 8.000
Specify the
width of the
slats.
F3 Wid
(Slat_Width)
0.000 to 1.000
Specify the
position of the
slats.
F4 Amt
(Amount)
–1.000 to 1.000
