Sony DFS-900M User Manual

209
Specifications
Appendix
Connector name plate (1)
+M3 screws (4), +M2.6 screws (4)
Operating Instructions (1)
Warranty (1)
BKDF-911 2 SD Video Input Board
Input connectors
BNC (4), equipped with down-
conversion function
Composite inputs
2 channels, 1.0 Vp-p, 75 ohms
Component input
1 channel
SD component
Y: 1.0 Vp-p, R–Y/B–Y: 0.7 Vp-p, 75
ohms
Power requirements
12 V DC (supplied from the switcher)
Power consumption
28 W max.
Operating temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Dimensions (w/d)
271×95 mm (10
3
/
4
× 3
3
/
4
inches) (not
including the projected parts)
Mass Approx. 300 g (11 oz)
Supplied accessories
Connector name plate (1)
+M3 screws (4), +M2.6 screws (4)
Heat transfer sheet (1)
Operating Instructions (1)
Warranty (1)
BKDF-912 2 DVI Input Board
Input connectors
DVI-I (2), female, single link,
incompatible with HDCP
1)
Resolution (DVI input)
RGB input R/G/B: 0.7 Vp-p
H/V: TTL level
Power requirements
12 V DC (supplied from the switcher)
Power consumption
38 W max.
Operating temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Dimensions (w/d)
271×95 mm (10
3
/
4
× 3
3
/
4
inches) (not
including the projected parts)
Mass Approx. 300 g (11 oz)
Supplied accessories
Connector name plate (1)
+M3 screws (4), hexagon head bolts (5
mm in width across flats) (4)
Heat transfer sheet (1)
Operating Instructions (1)
Warranty (1)
1) High-bandwidth Digital Content Protection
BKDF-940 2 CH DME Board
Power requirements
12 V DC (supplied from the switcher)
Power consumption
35 W max.
Operating temperature
5ºC to 40ºC (41ºF to 104ºF)
Dimensions (w/d)
110 × 130 mm (4
3
/
8
× 5
1
/
8
inches) (not
including the projected parts)
Mass Approx. 200 g (7.1 oz)
Supplied accessories
+M3 screws (4)
Heat transfer sheet (1)
Operating Instructions (1)
Warranty (1)
BKDF-950 Multi Viewer Board
Power requirements
12 V DC (supplied from the switcher)
Power consumption
20 W max.
Operating temperature
5ºC to 40ºC (41ºF to 104ºF)
Dimensions (w/d)
110 × 130 mm (4
3
/
8
× 5
1
/
8
inches) (not
including the projected parts)
Mass Approx. 200 g (7.1 oz)
Supplied accessories
+M3 screws (4)
Operating Instructions (1)
Warranty (1)
BKDF-960 4 SDI Output Board
Video output BNC type (4), 800 mVp-p, 75 ohms
HD-SDI: 1.485 Gbps or 1.485/
1.001 Gbps
SD-SDI: 270 Mbps
Of the four output channels, two channels
provided with down-conversion
function.
Power requirements
HD (1920×1080) HD (1280×720) SD
– – 640×480 (VGA)
– – 800×600
(SVGA)
1024×768 (XGA) 1024×768 (XGA) 1024×768 (XGA)
1280×768 (WXGA) 1280×768 (WXGA) –
1280×1024 (SXGA) 1280×1024
(SXGA)
–
1600×1200 (UXGA) – –
1680×1050
(WSXGA)
– –
1920×1200
(WUXGA)
– –
