Specifications
Appendix
12 V DC (supplied from the switcher)
Power consumption
20 W max.
Operating temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Dimensions (w/d)
271 × 110 mm (10
3
/
4
× 4
3
/
8
inches) (not
including the projected parts)
Mass Approx. 400 g (14 oz)
Supplied accessories
Connector name plate (1)
+M3 screws (4), +M2.6 screws (4)
Operating Instructions (1)
Warranty (1)
BKDF-961 2 SD Video Output Board
Output connectors
BNC (4), equipped with down-
conversion function
Composite inputs
2 channels, 1.0 Vp-p, 75 ohms
Component input
1 channel
SD component
Y: 1.0 Vp-p, R–Y/B–Y: 0.7 Vp-p, 75
ohms
Power requirements
12 V DC (supplied from the switcher)
Power consumption
21 W max.
Operating temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Dimensions (w/d)
271 × 110 mm (10
3
/
4
× 4
3
/
8
inches) (not
including the projected parts)
Mass Approx. 400 g (14 oz)
Supplied accessories
Connector name plate (1)
+M3 screws (4), +M2.6 screws (4)
Heat transfer sheet (1)
Operating Instructions (1)
Warranty (1)
BKDF-962 2 DVI Output Board
Input connectors
DVI-I (2), female, single link,
incompatible with HDCP
1)
Resolution (DVI input)
RGB input R/G/B: 0.7 Vp-p
H/V: TTL level
Power requirements
12 V DC (supplied from the switcher)
Power consumption
32 W max.
Operating temperature
5 ºC to 40 ºC (41 ºF to 104 ºF)
Dimensions (w/d)
271 × 110 mm (10
3
/
4
× 4
3
/
8
inches) (not
including the projected parts)
Mass Approx. 400 g (14 oz)
Supplied accessories
Connector name plate (1)
+M3 screws (4), hexagon head bolts (5
mm in width across flats) (4)
Heat transfer sheet (1)
Operating Instructions (1)
Warranty (1)
1) High-bandwidth Digital Content Protection
2) Only digital signals are output. Analog signals are not output.
BKDF-990 Power Supply Unit
Power requirements
100 to 240 V AC, 50/60 Hz
Supply voltage 12 V DC
Operating temperature
5ºC to 40ºC (41ºF to 104ºF)
Dimensions (w/h/d)
405 × 62.5 × 122.5 mm (16 × 2
1
/
2
×
4
7
/
8
inches) (not including the
projected parts)
Mass Approx. 3.1 kg (6 lb 13 oz)
Supplied accessories
Operating Instructions (1)
Warranty (1)
RMM-10 Rack Mount Kit
HD (1920×1080) HD (1280×720) SD
– – 800×600
(SVGA)
– 1280×768 (WXGA) –
1280×1024 (SXGA) 1280×1024
(SXGA)
–
1600×1200 (UXGA)
2)
––
1680×1050 (WSXGA) – –
1920×1080 (HDTV) – –
1920×1200 (WUXGA)
2)
––
HD (1920×1080) HD (1280×720) SD
