147MS 261, MS 261 C
14. Special Servicing Tools
Existing Special Tools
No. Description Part No. Application Rem.
1 Carburetor and engine tester 0000 850 1300 Testing engine and carburetor for leaks
- Nipple 0000 855 9200 Testing carburetor for leaks
- Hose for leakage test 1110 141 8600 Testing carburetor for leaks
- Plug for leakage test 1122 025 2200 Leakage testing decompression valve
2 Sealing plate 0000 855 8106 Testing crankcase for leaks
3 Installing tool 0000 890 2201 Installing rope guide bushing
4 Clamping strap 0000 893 2600 Compressing the piston rings
5 Locking strip 0000 893 5903 Blocking the crankshaft
6 Pliers DIN 5254-A 19 0811 611 8380 Removing and installing external
circlips
7 Screwdriver bit, T 27 x 125 0812 542 2104 Removing and installing spline socket
screws with electric or pneumatic
screwdrivers; tightening down screws
with torque wrench
8 Wooden assembly block 1108 893 4800 Supporting the piston
9 Assembly drift 1110 893 4700 Removing and installing piston pin
10 Setting gauge 1111 890 6400 Adjusting air gap between the ignition
module and flywheel
11 Installing tool 1116 893 4800 Installing rewind spring
12 Assembly tube 1117 890 0900 Attaching springs
13 Press sleeve 1118 893 2401 Installing oil seal
(clutch side)
14 Press arbor 1118 893 7200 Installing ball bearings
15 Test flange 1119 850 4201 Leakage Test
- Sleeve 5910 893 1701 Spacer sleeves for test flange
16 Combination wrench 1129 890 3401 Spark plug 1)
New Special Tools
No. Description Part No. Application Rem.
1 Press sleeve 1141 893 2400 Installing oil seal
(ignition side)
2 Installing sleeve 1141 893 4600 Protecting the oil seal
(clutch and ignition sides)
3 Screwdriver 5910 890 2306 Adjusting the carburetor
4 Puller 5910 890 4502 Pull off the limiter cap.
5 Puller 5910 890 4504 Removing flywheel
6 Installing tool 5910 893 9600 Removing and installing collar nuts in
sprocket cover
