Sub-Zero 501R User Manual

1 3410980 Egg Tray
2 3210710 Dairy Door Seal
3 3515600 Dairy Door
4 3550440 Door Shelf Retainer
5 3550490 Dairy Compartment Retainer
6 3600851 Dairy Compartment Outer End
Cap, RS
3600852 Dairy Compartment Outer End
Cap, LS
7 3600891 Dairy Compartment Inner End
Cap, RS
3600892 Dairy Compartment Inner End
Cap, LS
8 3600751 Door Shelf Outer End Cap, RS
3600752 Door Shelf Outer End Cap, LS
9 3600761 Door Shelf Inner End Cap, RS
3600762 Door Shelf Inner End Cap, LS
10 3600860 Dairy Compartment
11 3421060 Dairy Compartment Center Divider
12 3600970 Door Shelf
13 3510710 Door Shelf Support
14 4330300 Dairy Compartment Assembly
15 4330250 Door Shelf Assembly
16 3420250 Gasket Retainer, Side, 57.875"
17 6200410 Screw, #8 x 1/2" Slot Head Hex
18 2225301 Door Trim, Hinge Side
19 3420220 Gasket Retainer, 33.312"
20 6180040 Pop Rivet, 3/16x1/8 Grip
21 2225408 Door Trim, Top RH/Bottom LH, 45°
Miter on Handle Side
2225409 Door Trim, Top LH/Bottom RH, 45°
Miter on Handle Side
2225402 Door Trim, Top RH/Bottom LH
(Valanced Handle)
2225403 Door Trim, Top LH/Bottom RH
(Valanced Handle)
22 6200720 Screw, #8-18 x 1/2 PH Truss HD
23 NLA See EH501
24 3450460 Door Trim Clip
25 3211140 Door Gasket
26 3450450 Molding Magnet - 3"
27 2225801 Door Trim, Handle Side (45° Miter
- For D-Style Handle)
2225803 Door Trim, Handle Side (Valanced
- For D-Style Handle)
28 4131030 D-Style Handle Molding Assembly
(For Mitered Trim)
4131170 D-Style Handle Molding Assembly
(For Valanced Trim)
29 6200780 Screw, #10-24 x 1/2" PH Hex
Washer
30 6240020 Star Washer, 3/16"
31 6240240 Flat Washer, 1/4"
32 2225408 Door Trim, Top RH/Bottom LH, 45°
Miter on Handle Side
2225409 Door Trim, Top LH/Bottom RH, 45°
Miter on Handle Side
2225402 Door Trim, Top RH/Bottom LH
(Valanced Handle)
2225403 Door Trim, Top LH/Bottom RH
(Valanced Handle)
33 0180281 Switch Depressor, White
34 6200020 Screw, #7-16 x 1/2" Pan HD
35 4131121 Door Assembly, Ref; RH
4131122 Door Assembly, Ref; LH
36 NLA See EH501
NLA See EH501
37 4200760 Door Trim Components for D-Style
Valanced Handle
4200690 D-Style Handle End Cap
Replacement Components
501R DOOR VIEW
Ref. Part No. Description
Ref. Part No. Description
EXPLODED VIEWS & PARTS LISTS
4-2
