16-26 DF90/115/140 “K6” (’06) MODEL
CLAMP BRACKET SHAFT AND BUSHING
The clamp bracket shaft has been redesigned with a clearance hole in place of a slot for routing the grease
lubrication.
NOTE:
Install the clamp bracket shaft with “Red” paint marking toward
up side.
The clamp bracket shaft bushing has been redesigned with slot in place of two holes to provide routing for
the grease lubrication.
Grease groove
Yellow paint mark
Grease hole
Red paint mark
Locating hole
Locating hole
Red paint mark
Grease holes
Grease groove
