Suzuki DF140WT User Manual

16-30 DF90/115/140 “K6” (’06) MODEL
2. Remove the upper thrust reverse mount 3.
3. Remove the two nuts 4 and upper mount plate 5.
4. Remove the four bolts 6 and upper mount covers 7.
Remove the upper mount assembly.
Reassemble the upper mount
When reassembling the upper mount parts, follow the removal
instruction in reverse. Also, paying close attention the parts ori-
entation shown below.
Install the upper mount plate with the UP mark pointing upside.

Suzuki DF140WT Specifications

General

Brand	Suzuki
Model	DF140WT
Category	Outboard Motor
Language	English
