CLUTCH 7-5
CLUTCH SPRING
• Measure the clutch spring free length.
• Replace all the springs if any spring is not within the limit.
NOTE:
Replace five clutch springs together even if only one spring is
beyond the service limit.
# Clutch spring free length
Service Limit: 43.0 mm (1.69 in)
" 09900-20101: Vernier calipers (150 mm)
PUSH ROD
• Inspect the push rod for wear and damage.
• If any defects are found, replace the push rod with a new one.
RELEASE BEARING
• Inspect the clutch release bearing for any abnormality, partic-
ularly cracks, to decide whether it can be reused or should be
replaced.
• Smooth engagement and disengagement of the clutch
depends on the condition of this bearing.
