FRONT AND REAR WHEELS 15-11
INSTALLATION
• Install the rear wheel, chain adjuster washers and axle shaft.
• Adjust the drive chain slack. ('2-28)
• Tighten the rear axle nut to the specified torque.
& Rear axle nut: 90 N·m (9.0 kgf-m, 65.0 lb-ft)
REAR WHEEL SPOKES REPLACEMENT
('19-30)
FWD
Left
Right
Chain adjuster washer
